Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT Advent X -
Suspension Rigid -
Motor MAHLE 250W 40Nm hub-drive -
Battery MAHLE ebikemotion X35 250Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 172cm
MD
170cm - 182cm
LG
179cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Grade Alloy Triple Triangle frame, Ebikemotion specific design, Internal Battery, Tapered Head Tube
Suspension Fork
GT Grade E-Carbon, 1.5" Tapered Carbon Steerer, 12x100 Thru-Axle
Drivetrain
Rear Derailleur
MicroSHIFT M6205
Shift Levers
MicroSHIFT M100, 10-speed
Cassette
microSHIFT, 11-48T
Crank
Prowheel Charm, 40T
Bottom Bracket
BSA, Square Taper
Chain
KMC X10, 10-speed
Pedals
Not included
Wheels
Front Hub
Formula, 12x100mm, 32H
Rear Hub
eBikemotion X35+, 32H
Rims
Shining, 32h
Tires
Front: WTB Nano Comp, 700 x 40, Tubeless Ready, Rear: WTB Nano Comp, 700 x 40, Tubeless Ready
Brakes
Brakes
Shimano MT200 Hydro Disc, 160/160mm Rotors
Cockpit
Stem
GT All Terra 3D Forged Alloy, 31.8
Handlebar
GT Alloy Flat Bar 640mm
Grips
Fabric Silicone Cell
Headset
1.5" Lower to 1-1/8" Upper w/ Reducer, 25mm Alloy Top Cap
Seat
Saddle
Fabric Scoop Shallow/ Sport, Steel Rails
Seatpost
GT All Terra Two Bolt Alloy
Motor & Battery
Motor
MAHLE ebikemotion X35 250W
Battery
MAHLE ebikemotion X35 250Wh
Charger
X35 Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.429 mm | 1.425 mm | 1.419 mm | 1.416 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 617 mm | 621 mm | 641 mm | 662 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 72 mm | 82 mm | 89 mm | 98 mm |
| Stack | 550 mm | 577 mm | 603 mm | 630 mm |
| Reach | 385 mm | 405 mm | 425 mm | 445 mm |
| Top Tube Length | 545 mm | 562 mm | 581 mm | 601 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 458 mm | 505 mm | 553 mm | 600 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 124 mm | 150 mm | 183 mm | 214 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1062 mm | 1065 mm | 1086 mm | 1107 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 741 mm | 782 mm | 822 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 170 cm | 179 cm | 187 cm |
| Rider Max Height | 172 cm | 182 cm | 189 cm | 195 cm |
