Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox 35 Silver
-
Groupset microSHIFT Advent X -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
165cm - 180cm
LG
177cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Force Alloy 29" Frame, 150mm travel, 12x148mm Thru-Axle
Suspension Fork
RockShox 35 Silver TK, 160mm, 44mm Offset
Rear Shock
RockShox Deluxe Select R, 185x55mm Trunnion
Drivetrain
Rear Derailleur
MicroSHIFT Advent X, M6205
Shift Levers
MicroSHIFT Advent X, 10-Speed
Cassette
MicroSHIFT Advent X, 11-48T
Crank
Prowheel MPX, 32T
Bottom Bracket
Shimano BSA, 73mm
Chain
KMC X10, 10-Speed
Wheels
Front Hub
Formula, 15x110mm
Rear Hub
Formula, 12x148mm, HG Freehub Body
Rims
WTB ST i30 TCS 2.0, 32h, Tubeless Ready
Tires
Front: Maxxis Minion DHF, 29x2.5", EXO, Rear: Maxxis Minion DHR II, 29x2.5", EXO
Brakes
Brakes
Tektro M275, 180/180mm Rotors
Cockpit
Stem
GT Alloy, 45mm
Handlebar
GT Alloy Riser Bar, 30mm Rise, 780mm, 5° Up, 8° Back
Grips
GT Mushroom
Headset
FSA No.42
Seat
Saddle
WTB Silverado Sport
Seatpost
TranzX Dropper, 31.6mm, (S - 120mm, M - 150mm, L/XL - 170mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.464 mm | 1.398 mm | 1.338 mm | 1.285 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 757 mm | 785 mm | 814 mm | 842 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 615 mm | 622 mm | 629 mm | 636 mm |
| Reach | 420 mm | 445 mm | 470 mm | 495 mm |
| Top Tube Length | 567 mm | 594 mm | 621 mm | 647 mm |
| Seat Tube Angle | 76.5 ° | 76.6 ° | 76.6 ° | 76.6 ° |
| Seat Tube Length | 420 mm | 440 mm | 460 mm | 480 mm |
| Head Tube Angle | 64.5 ° | 64.6 ° | 64.6 ° | 64.6 ° |
| Head Tube Length | 102 mm | 110 mm | 118 mm | 126 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1198 mm | 1226 mm | 1254 mm | 1283 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 736 mm | 756 mm | 775 mm | 795 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 165 cm | 177 cm | 185 cm |
| Rider Max Height | 167 cm | 180 cm | 188 cm | 198 cm |
