Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
100% Cr-Mo, DT Gusset, Mid BB, Seat Stay U-Brake, Integrated 1-1/8" H/T w/ Removable Rotor Tabs
Suspension Fork
100% Cr-Mo, 1pc Threaded Steerer, Tapered Legs, 31mm Offset
Drivetrain
Cassette
9T 1pc. Driver
Crank
GT Power Series 3pc Chromoly 170mm, 22mm x 48T Spindle, GT NBS 25T Alloy Chainwheel
Bottom Bracket
Sealed Mid 22mm
Chain
KMC HL1 Wide
Pedals
GT Logo PC Platform
Wheels
Front Hub
Alloy Sealed 3/8" Female Axle
Rear Hub
Alloy Sealed 14mm Cassette
Rims
Alloy Double Wall, 36h
Spokes
Stainless Steel, 14g
Tires
Front: Innova 2.3", Rear: Innova 2.3"
Brakes
Brakes
NBS Alloy U-Brake w/ Soft Compound Pad
Brake Levers
NBS Hinged Alloy
Cockpit
Stem
GT NBS Top Load 50mm, 32mm Rise
Handlebar
GT 2pc Freestyle, 100% Cr-Mo, 9"H x 29"W, 3°Up, 11° Back
Grips
GT Super Soft Flangeless
Headset
1-1/8" Sealed Integrated (41.8 x 45)
Seat
Saddle
GT Pivotal Padded
Seatpost
Alloy Pivotal, 25.4 x 200mm
Fit data
Geometry
