Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 172cm
MD
170cm - 182cm
LG
179cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Grade Carbon Frame, Triple Triangle Design feat. Floating Seatstays, 12x142mm Thru Axle, 45mm Max Tire Width
Suspension Fork
Grade Carbon Fork, 1.5 Tapered Carbon Steerer, 12x100 Thru Axle
Drivetrain
Rear Derailleur
Shimano GRX RD-RX822
Shift Levers
Shimano GRX BR-RX820
Cassette
Shimano CS-M7100, 10-45T
Crank
Shimano GRX FC-RX820, 40T
Bottom Bracket
Shimano BB-RS501
Chain
Shimano CN-M7100, 12-Speed
Wheels
Front Hub
WTB SpeedTerra, 12x100mm, Centerlock
Rear Hub
WTB SpeedTerra, 12x142mm, Centerlock
Rims
WTB SpeedTerra i23 TCS 2.0, 28h, Tubeless Ready
Tires
Front: WTB Vulpine TCS Light, 700x40c, Dual DNA Compound, TCS Aramid Bead, Rear: WTB Vulpine TCS Light, 700x40c, Dual DNA Compound, TCS Aramid Bead
Brakes
Brakes
Shimano GRX BR-RX820
Cockpit
Stem
GT 3D Forged SL Alloy, 31.8
Handlebar
GT DropTune Super Light, Double Butted 6061 Alloy, Flat Top, 16° Flare (Width: S - 42cm, M & L -44cm, XL - 46cm)
Grips
GT Gravel Grip Premium Tape
Headset
FSA No.42 ACB
Seat
Saddle
WTB Silverado SL Fusion
Seatpost
GT Carbon, 27.2mm 350mm (S/M/L-350mm), XL-400mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.429 mm | 1.425 mm | 1.419 mm | 1.416 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 621 mm | 650 | 680 mm | 710 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 72 mm | 72 mm | 72 mm | 72 mm |
| Stack | 550 mm | 577 mm | 603 mm | 630 mm |
| Reach | 385 mm | 405 mm | 425 mm | 445 mm |
| Top Tube Length | 553 mm | 581 mm | 609 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 106 mm | 134 mm | 162 mm | 191 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1040 mm | 1069 mm | 1099 mm | 1129 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 730 mm | 753 mm | 792 mm | 816 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 170 cm | 179 cm | 187 cm |
| Rider Max Height | 172 cm | 182 cm | 189 cm | 195 cm |
