Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT Advent X -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
160cm - 172cm
MD
170cm - 182cm
LG
179cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Grade Alloy Triple Triangle frame, 12x142 Thru Axle, Threaded BB, 45mm Max Tire Width
Suspension Fork
Grade Carbon Fork, 1.5 Tapered Carbon Steerer, 12x100 Thru Axle
Drivetrain
Rear Derailleur
MicroShift Advent X with Clutch
Front Derailleur
N/A
Shift Levers
MicroShift Dual Control Advent X, 10-speed
Cassette
MicroShift CS-G104, 11-48T
Crank
ProWheel Charm, 40T
Bottom Bracket
BSA, Square Taper
Chain
KMC X10, 10-speed
Wheels
Front Hub
Formula, 12x100 6-bolt, 28H
Rear Hub
Formula, 12x142, 6-bolt, 28H
Rims
WTB ST i23 TCS 2.0, 28h, Tubeless Ready
Tires
Front: WTB Riddler, 700 x 37c, Rear: WTB Riddler, 700 x 37c
Brakes
Brakes
PROMAX DSK-330 Mech, 160/160mm Rotors
Cockpit
Stem
GT 3D Forged SL Alloy, 31.8
Handlebar
GT DropTune RS, Alloy, 10° Flare
Grips
Velo Cork, 3mm
Headset
FSA No.42 ACB
Seat
Saddle
GT Pavement, Steel Rails
Seatpost
GT Alloy, 27.2 x 350mm (44-58), 400mm (61)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.466 mm | 1.429 mm | 1.425 mm | 1.419 mm | 1.416 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 605 mm | 621 mm | 651 mm | 680 mm | 709 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 79 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Stack | 535 mm | 550 mm | 577 mm | 603 mm | 630 mm |
| Reach | 365 mm | 385 mm | 405 mm | 425 mm | 445 mm |
| Top Tube Length | 529 mm | 553 mm | 581 mm | 609 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 94 mm | 106 mm | 134 mm | 162 mm | 191 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1034 mm | 1050 mm | 1080 mm | 1109 mm | 1139 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 692 mm | 727 mm | 765 mm | 805 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 160 cm | 170 cm | 179 cm | 187 cm |
| Rider Max Height | 165 cm | 172 cm | 182 cm | 189 cm | 195 cm |
