Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Manitou Circus Expert
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 180cm
LG
177cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum, BSA BB, Disc Brake Mount, Integrated 1-1/8"-1.5" Taper H/T, 3/8" Horizontal Adjustable Dropout w/ Integrated Chain Tensioners
Suspension Fork
Manitou Circus Expert, Coil w/ Rebound Adjust, 20mm Thru Axle, 1-1/8"-1.5" Taper AL Steerer, 100mm Travel, Pre Load Adjust, Black Stanchions
Drivetrain
Cassette
13T Cog
Crank
GT Power Series 3pc Chromoly 170mm, 22mm x 48T Spindle, GT NBS 28T Alloy Chainwheel
Bottom Bracket
BSA Sealed
Chain
KMC HL1 Wide
Pedals
GT Logo PC Platform
Wheels
Front Hub
Sealed Alloy Disc, 20mm
Rear Hub
Alloy Disc Body, Sealed Bearings, 32 Hole, 3/8" x 17mm Female Bolt
Rims
Alloy Double Wall, 32h
Spokes
Stainless Steel, 14g
Tires
Front: Kenda 3-Sixty 2.35", Rear: Kenda 3-Sixty 2.35"
Brakes
Brakes
Hydro Disc, 160mm Rotor
Brake Levers
2 Finger Hydro
Cockpit
Stem
GT 3D Forged Alloy Stem 35mm, 31.8mm Clamp
Handlebar
GT Alloy Riser Bar, 30mm Rise, 780mm Wide, 5° Up, 8° Back
Grips
GT Super Soft Flanged
Headset
1-1/8-1.5" Taper Sealed Integrated, (45)
Seat
Saddle
GT Pivotal Slim Padded
Seatpost
Alloy Pivotal 27.2 x 200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.448 mm | 1.349 mm |
| Bottom Bracket Height | 334 mm | 334 mm |
| Front Center | 673 mm | 702 mm |
| Rake | 41 mm | 41 mm |
| Trail | 90 mm | 90 mm |
| Stack | 588 mm | 588 mm |
| Reach | 406 mm | 436 mm |
| Top Tube Length | 570 mm | 590 mm |
| Seat Tube Angle | 75.6 ° | 75.6 ° |
| Seat Tube Length | 334 mm | 334 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 110 mm |
| Chainstay Length | 378 mm | 378 mm |
| Wheelbase | 1057 mm | 1087 mm |
| Bottom Bracket Drop | 25 mm | 25 mm |
| Standover Height | 691 mm | 691 mm |
| Wheels | 26" | 26" |
| Rider Min Height | 165 cm | 177 cm |
| Rider Max Height | 180 cm | 188 cm |
