Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Mechanical Disc
Sizing
Recommended size guide.
MD
165cm - 180cm
LG
177cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum, BSA BB, Disc Brake Mount, Integrated 1-1/8"-1.5" Taper H/T, 3/8" Horizontal Adjustable Dropout w/ Integrated Chain Tensioners
Suspension Fork
GT Pro Pump Track Design, 100% Cr-Mo, 1pc Steerer, Tapered Legs, IS Disc Mount
Drivetrain
Cassette
13T Cog
Crank
GT Power Series 3pc Chromoly 170mm, 19mm x 8T Spindle, GT NBS 28T Alloy Chainwheel
Bottom Bracket
BSA Sealed
Chain
KMC HL1 Wide
Pedals
GT Logo PC Platform
Wheels
Front Hub
(F) Sealed Alloy Disc, 9mm QR / (R) Alloy Disc Body, Sealed Bearings, 3/8" x 17mm Female Bolt Cassette
Rear Hub
(F) Sealed Alloy Disc, 9mm QR / (R) Alloy Disc Body, Sealed Bearings, 3/8" x 17mm Female Bolt Cassette
Rims
Alloy Double Wall, 32h
Spokes
Stainless Steel, 14g
Tires
Front: Kenda 3-Sixty 2.35", Rear: Kenda 3-Sixty 2.35"
Brakes
Brakes
Mechanical Disc, 160mm Rotor (F/R)
Brake Levers
Alloy, 2 Finger
Cockpit
Stem
GT All Terra 3D Forged Alloy 35mm, 31.8 Clamp
Handlebar
GT Alloy Riser Bar, 30mm Rise, 780mm Wide, 5° Up, 8° Back
Grips
GT Super Soft Flanged
Headset
1-1/8-1.5" Taper Sealed Integrated, (45)
Seat
Saddle
GT Pivotal Slim Padded
Seatpost
Alloy Pivotal 27.2 x 200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.448 mm | 1.349 mm |
| Bottom Bracket Height | 334 mm | 334 mm |
| Front Center | 673 mm | 702 mm |
| Rake | 41 mm | 41 mm |
| Trail | 90 mm | 90 mm |
| Stack | 588 mm | 588 mm |
| Reach | 406 mm | 436 mm |
| Top Tube Length | 570 mm | 590 mm |
| Seat Tube Angle | 75.6 ° | 75.6 ° |
| Seat Tube Length | 334 mm | 334 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 110 mm |
| Chainstay Length | 378 mm | 378 mm |
| Wheelbase | 1057 mm | 1087 mm |
| Bottom Bracket Drop | 25 mm | 25 mm |
| Standover Height | 691 mm | 691 mm |
| Wheels | 26" | 26" |
| Rider Min Height | 165 cm | 177 cm |
| Rider Max Height | 180 cm | 188 cm |
