Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Mach One Race MK2, 6061 Alloy, Euro BB, Reverse Dropouts, V-Brakes, 1-1/8" Integrated H/T
Suspension Fork
GT BMX Race, Hi-Ten Steel 1 1/8" Steerer, Tapered Legs, 366mm A/C, 3/8" Dropouts
Drivetrain
Cassette
18T Freewheel
Crank
GT Power Series Tubular Cr-Mo 3pc. 175mm Arms, 19mm x 8T Splined Spindle, 110 BCD Steel Spider, GT 42T Steel Chainring
Bottom Bracket
Euro Sealed Bearing
Chain
KMC S1
Pedals
GT Low Profile FS Platform Design
Wheels
Front Hub
Steel Body, 36H, 3/8" Axle
Rear Hub
Steel Flip Flop Thread-on Body, Freewheel, 36h, 3/8" Axle
Rims
Alloy Single Wall, 36h
Spokes
Stainless Steel, 14g
Tires
Front: GT Wing 24 x 2.1", Rear: GT Wing 24 x 1.75"
Brakes
Brakes
Alloy V-type
Brake Levers
Alloy V-type
Cockpit
Stem
GT Top Load, 50mm
Handlebar
GT Race, Steel, 6.5"H x 29"W, 4° Up, 8° Back
Grips
GT Statement
Headset
1-1/8" Sealed Integrated (41.8 x 45)
Seat
Saddle
Railed
Seatpost
Alloy, 27.2mm x 200mm
Fit data
Geometry
