Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Travel Front 75mm -
Fork Suntour
-
Groupset microSHIFT M26 -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 177cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hi-Tensile Steel Triple Triangle™ Frame, w/ 1 1/8" Head Tube
Suspension Fork
SR Suntour M3030, 75mm, Coil
Drivetrain
Rear Derailleur
microSHIFT RD-M26
Front Derailleur
microSHIFT FD-M20M
Shift Levers
microSHIFT TS38 7-speed
Cassette
Sunrace, 14-34T, 7-speed
Crank
ProWheel 42/34/24T
Bottom Bracket
BSA Sealed
Chain
KMC Z7, 7-speed
Pedals
GT Slim Line Flat Pedal
Wheels
Front Hub
Alloy, QR, 32H
Rear Hub
Alloy F/W, QR, 32H
Rims
All Terra Double Wall, 32h
Brakes
Brakes
Alloy V-type
Brake Levers
Alloy V-type
Cockpit
Stem
GT Alloy, 31.8, 8° up
Handlebar
GT Alloy Riser, 25mm Rise, 720mm Width, 6° up, 8° back
Grips
GT Statement
Headset
1 1/8 Ahead Type
Seat
Saddle
GT MTB
Seatpost
Alloy 27.2 x 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Wheels | 26" | 26" |
| Rider Min Height | 152 cm | 164 cm |
| Rider Max Height | 167 cm | 177 cm |
