Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
100% Hi-Ten Steel Tubes, DT Gusset, American BB, Under Seat Stay V-Brake, External 1-1/8" H/T, Removable Rotor Tabs
Suspension Fork
100% Hi-Ten, 2pc. Steerer, Tapered Legs
Drivetrain
Cassette
16T Freewheel
Crank
GT Power Series 3pc Chromoly 170mm, 19mm x 8T Spindle, GT NBS 33T Steel Chainwheel
Bottom Bracket
American Loose Ball Bearing
Chain
KMC S1
Pedals
GT Logo PC Platform
Wheels
Front Hub
Steel Loose Ball 3/8" Axle
Rear Hub
Steel Flip Flop Thread-On Body Sealed, 3/8" Axle
Rims
Alloy Single Wall (F), Double Wall (R), 36h
Spokes
Stainless Steel, 14g
Tires
Front: GT Smoothie 2.5", Rear: GT Smoothie 2.5"
Brakes
Brakes
Aluminum V-Brake
Brake Levers
Alloy V-type
Cockpit
Stem
GT NBS Front Load 40mm, 10mm Rise
Handlebar
GT 2pc Freestyle, 100% Hi-Ten Steel, 7.875"H x 31.5"W, 5°Up, 11° Back
Grips
GT Super Soft Flanged
Headset
1-1/8" Threadless, Steel
Seat
Saddle
GT Cheat Code Railed
Seatpost
Alloy Micro Adjust 27.2 x 300mm
Fit data
Geometry
