Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT Advent -
Suspension Rigid -
Motor Bafang 250W 45Nm hub-drive -
Battery Removable, 504Wh, 1.5amp USB Charging Port -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Power Performer eBike, 6061 Series Alloy, Floating Frame Stander Seat Stays, Threaded BB, Plate Disc Mount Dropouts, Semi-Integrated 1-1/8" H/T, 2.5" Tire Clearance, Utility Braze Ons
Suspension Fork
GT Power Performer, Alloy Leg Blades and Crown, 1-1/8" Steel Steerer, 55mm Street Rake Offset, Post Mount Disc, Internal Mid-Blade/Dropout Mounts
Drivetrain
Rear Derailleur
microSHIFT, Advent, 1 x 9 with Clutch
Shift Levers
microSHIFT, 1 x 9 Advent, 9-speed
Cassette
Sunrace, 11-36T, 9-speed
Crank
GT Power Series 3pc Alloy 170mm, Square Taper Spindle, 104 BCD Narrow Wide 38T Steel Chainwheel, Alloy Guard
Bottom Bracket
Threaded, Square Type
Chain
KMC E9T
Pedals
GT Logo PC Platform
Wheels
Front Hub
Alloy Disc Hub, 36h, 6 Bolt, Hex Wrench QR
Rear Hub
Bafang 36v/250w, OLD= 138mm, 6 Bolt, Shimano Type Cassette, 9 Speed, Nutted Axle
Rims
Alloy Double Wall, 36h
Spokes
(F) Stainless Steel, 14g / (R) Stainless Steel, 13g
Tires
Front: GT Smoothie Session 2.5", Light Guard 1.2mm, Reflective Sidewall, Rear: GT Smoothie Session 2.5", Light Guard 1.2mm, Reflective Sidewall
Brakes
Brakes
Hydro Disc, 160/160mm Rotors
Brake Levers
Alloy, 2 Finger
Cockpit
Stem
GT NBS Front Load 40mm, 10mm Rise
Handlebar
GT Power Performer 4pc. 100% Cr-Mo, 7.25"H x 29"W, 4°Up, 12° Back
Grips
GT Super Soft Flangeless
Headset
1 1/8" Semi-Integrated
Seat
Saddle
GT Comfy Code Railed
Seatpost
Alloy Micro Adjust 27.2 x 350mm
Motor & Battery
Motor
Bafang 36v/250w, Torque= 45Nm
Battery
Removable, 504Wh, 1.5amp USB Charging Port
Charger
2 Amp Battery Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.509 mm |
| Bottom Bracket Height | 315 mm |
| Front Center | 652 mm |
| Rake | 55 mm |
| Trail | 71 mm |
| Stack | 608 mm |
| Reach | 403 mm |
| Top Tube Length | 600 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 460 mm |
| Head Tube Angle | 71 ° |
| Head Tube Length | 131 mm |
| Chainstay Length | 473 mm |
| Wheelbase | 1119 mm |
| Bottom Bracket Drop | 60 mm |
| Standover Height | 789 mm |
| Wheels | 29" |
| Rider Min Height | 120 cm |
