Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT 86' Pro Performer, 100% Cr-Mo, DT Gusset, Mid BB, Chain Stay Mounted U-Brake, Integrated 1-1/8" H/T w/ Removable Rotor Tabs
Suspension Fork
GT 86' Pro Performer, 100% Cr-Mo, 1pc. Threaded Steerer, Tapered Legs, 31mm Offset, Brake Mounts
Drivetrain
Cassette
9T 1pc. Driver
Crank
GT Power Series Alloy 3pc. 175mm Arms, 22mm Chromoly Spindle, GT NBS 28T Alloy Chainwheel
Bottom Bracket
Sealed Mid 22mm
Chain
KMC HL1 Wide
Pedals
GT Logo PC Platform
Wheels
Front Hub
GT Superlace High, Alloy Sealed, 3/8" Female Axle
Rear Hub
GT Superlace High, Alloy Sealed, 3/8" Female Cassette
Rims
Alloy Double Wall, 36h
Spokes
Stainless Steel, 14g
Tires
Front: GT LP-5 2.35", Rear: GT LP-5 2.2"
Brakes
Brakes
SST ORYG Detangler, Alloy U-Brake (F/R)
Brake Levers
NBS Hinged Alloy
Cockpit
Stem
GT Mallet Front Load 43mm, 100% CNC, 19mm Rise
Handlebar
GT 2pc Performer, 100% Cr-Mo, 9.125"H x 29"W, 5°Up, 9° Back
Grips
GT Super Soft Flangeless
Headset
1-1/8" Sealed Integrated (41.8 x 45)
Seat
Saddle
GT Pivotal Padded
Seatpost
Alloy Pivotal Layback, 25.4 x 300mm
Fit data
Geometry
