Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 140mm -
Travel Rear 120mm -
Fork RockShox Pike Select+
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
165cm - 180cm
LG
177cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sensor ST Carbon 29” Frame, 120mm Travel, 12x148mm Thru-Axle, UDH
Suspension Fork
RockShox Pike Select + RC2, 140mm, Charger 3, DebonAir+, 44mm Offset
Rear Shock
RockShox Deluxe Select + RT, 185x47.5mm Trunnion
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX Eagle, 12-Speed
Cassette
SRAM PG-1230, 11-50T
Crank
Truvativ Stylo 6K, DUB, 32T
Bottom Bracket
SRAM DUB BSA, 73mm
Chain
SRAM NX Eagle, 12-Speed
Wheels
Front Hub
Formula, 15x110mm
Rear Hub
Formula, 12x148mm, HG Freehub Body
Rims
WTB KOM Trail i27, 32h, Tubeless Ready
Tires
Front: Maxxis Dissector, 29x2.4", 3C MaxxTerra, EXO, Rear: Maxxis Rekon, 29x2.4", 3C MaxxTerra, EXO
Brakes
Brakes
SRAM G2 RSC, 180/180mm Centerline Rotors
Cockpit
Stem
GT Alloy, 45mm
Handlebar
GT Alloy Riser Bar, 20mm Rise, 780mm, 5° Up, 8° Back (Width: S/M/L/XL - 80cm)
Grips
GT Mushroom
Headset
FSA No.42
Seat
Saddle
WTB Silverado
Seatpost
GT DropKick, 31.6mm, (S - 125mm, M - 150mm, L/XL - 170mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.428 mm | 1.367 mm | 1.315 mm | 1.244 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 750 mm | 779 mm | 808 mm | 848 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 125 mm | 125 mm | 125 mm | 125 mm |
| Stack | 621 mm | 629 mm | 638 mm | 647 mm |
| Reach | 435 mm | 460 mm | 485 mm | 520 mm |
| Top Tube Length | 573 mm | 600 mm | 627 mm | 664 mm |
| Seat Tube Angle | 77.4 ° | 77.4 ° | 77.4 ° | 77.4 ° |
| Seat Tube Length | 380 mm | 400 mm | 420 mm | 460 mm |
| Head Tube Angle | 65.4 ° | 65.4 ° | 65.4 ° | 65.4 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1187 mm | 1216 mm | 1246 mm | 1285 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 711 mm | 721 mm | 731 mm | 741 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 165 cm | 177 cm | 185 cm |
| Rider Max Height | 167 cm | 180 cm | 188 cm | 198 cm |
