Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Sizing
Recommended size guide.
Junior
129cm - 139cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Speed Series MK7 Junior Race, 6061-T6 AL, Alloy Formed and Butted Speed Metal Tubes, Reverse Dropouts, Euro BB, 1" Integrated H/T
Suspension Fork
GT BMX Junior Race, 6061 AL 1" Steerer, 312mm A/C, 3/8" Dropouts
Drivetrain
Cassette
16T Cog
Crank
GT Forged Alloy 2pc. 155mm Arms, 24mm Hollow/ Alloy Spindle, 104 BCD 40T AL CNC Chain Ring, Alloy Chain Ring Bolts
Bottom Bracket
EB24 Sealed Bearings
Chain
KMC Z1 Narrow, 3/32"
Pedals
GT Mini Platform
Wheels
Front Hub
GT Speed Series, Alloy Sealed, 3/8" Female Allen Bolt
Rear Hub
GT Speed Series, Alloy Sealed 3/8" Female Allen Bolt Cassette
Rims
Alloy Double Wall, 28h
Spokes
Stainless Steel, 14g
Tires
Front: Kenda Kompact Pro Race 1-3/8", Rear: Kenda Kompact Pro Race 1-1/8"
Brakes
Brakes
Promax MV-87, 85mm Cold Forged AL Arms, Mini V-Type
Brake Levers
Alloy V-type
Cockpit
Stem
GT Top Load, Cold Forged 1", 40mm
Handlebar
GT Speed Alloy 4"H x 24"W, 8° Back, 2° Up, Taper Cross Bar
Grips
GT Statement
Headset
1" Sealed Integrated (38.2 x 45)
Seat
Saddle
BOX Echelon
Seatpost
Integrated
Fit data
Geometry
