Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XL
167cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Speed Series MK7 Elite Race, 6061-T6 AL, Alloy Formed and Butted Speed Metal Tubes, AL CNC/Forged Quick Change Disc Dropout SyStem, BB86, Taper 1-1/8-1.5" Integrated H/T
Suspension Fork
GT BMX Pro Race, 100% Cr-Mo 1 1/8" Steerer, Tapered Legs, 354mm A/C, 3/8" Dropouts
Drivetrain
Cassette
18T Cog
Crank
GT Forged Alloy 2pc. 180mm Arms, 24mm Hollow/ Cr-Mo Spindle, 104 BCD 41T AL CNC Chain Ring, Alloy Chain Ring Bolts
Bottom Bracket
BB86 Sealed Bearings
Chain
KMC Z1 Narrow, 3/32"
Pedals
GT Logo PC Platform
Wheels
Front Hub
GT Speed Series, Alloy Sealed, 3/8" Female Allen Bolt
Rear Hub
GT Speed Series, Alloy Sealed, 6 Pawl 72point Alloy Cassette Body, 3/8" Female Allen Bolt Cassette
Rims
Alloy Double Wall, 36h
Spokes
Stainless Steel, 14g
Tires
Front: Kenda Konversion Pro Race 1.75", Rear: Kenda Konversion Pro Race 1.75"
Brakes
Brakes
Hydro Disc Rear, 140mm Rotor (Rear Only)
Brake Levers
Alloy, 2 Finger
Cockpit
Stem
Promax Impact Top Load, 53mm
Handlebar
GT Speed Cr-Mo 6.5"H x 29"W, 8° Sweep, 4° Up, Taper Cross Bar
Grips
GT Statement Double Lock-on Grips
Headset
1-1/8-1.5" Taper Sealed Integrated, (45)
Seat
Saddle
BOX Echelon
Seatpost
Integrated
Fit data
Geometry
