Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Groupset microSHIFT M21 -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
24" GT LegitFit Design, Alloy w/ Replaceable Hanger
Suspension Fork
All Terra CH-565, 50mm, Coil
Drivetrain
Rear Derailleur
microSHIFT RD-M21L
Shift Levers
microSHIFT MS29-7, 7-speed
Cassette
Shimano TZ500, 14-28, 7-speed Freewheel
Crank
Prowheel w/ Double Guard, 30T, 130mm
Bottom Bracket
Cartridge Sealed
Chain
KMC Z7, 7-speed
Pedals
GT BMX Flat Pedal, Resin
Wheels
Front Hub
Alloy, QR
Rear Hub
Alloy Freewheel, QR
Rims
All Terra Double Wall, 28h
Spokes
Stainless Steel, 14g
Tires
Front: Kenda Small Block Eight 24 x 2.10", Rear: Kenda Small Block Eight 24 x 2.10"
Brakes
Brakes
GT V-Brake
Brake Levers
Tektro 3 Finger
Cockpit
Stem
Alloy Ahead, 30mm
Handlebar
Steel Riser Bar, 20mm Rise, 540mm Width
Grips
GT MTB
Headset
1 1/8" Ahead
Seat
Saddle
GT MTB
Seatpost
Alloy Micro Adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.437 mm |
| Bottom Bracket Height | 243 mm |
| Front Center | 474 mm |
| Rake | 40 mm |
| Trail | 57 mm |
| Stack | 411 mm |
| Reach | 286 mm |
| Top Tube Length | 452 mm |
| Seat Tube Angle | 68 ° |
| Seat Tube Length | 255 mm |
| Head Tube Angle | 69.5 ° |
| Head Tube Length | 88 mm |
| Chainstay Length | 366 mm |
| Wheelbase | 839 mm |
| Bottom Bracket Drop | 23 mm |
| Standover Height | 516 mm |
| Wheels | 24" |
