Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
142cm - 154cm
SM
151cm - 167cm
MD
164cm - 179cm
LG
176cm - 187cm
XL
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Alloy Triple Triangle, 700c, replaceable hanger
Suspension Fork
GT Hi-Ten Steel Fork, Rack and Fender Eyelets
Drivetrain
Rear Derailleur
microSHIFT RD-M26C
Front Derailleur
microSHIFT FD-M20M
Shift Levers
microSHIFT TS38-7, 3x7
Cassette
Sunrace, 11-28T
Crank
ProWheel 42/34/24T
Bottom Bracket
BSA, Square Taper
Chain
KMC Z7, 7-speed
Pedals
GT Slim Line Flat Pedal
Wheels
Front Hub
Formula, QR, 32h
Rear Hub
Formula, QR, 32h
Rims
ALEX, Double Wall Alloy, 32h
Brakes
Brakes
Mech Disc, 160/160mm Rotors
Cockpit
Stem
GT Alloy, 31.8, 8° up
Handlebar
GT Alloy Riser, 25mm Rise, 640mm Width, 6° up, 8° back
Grips
GT Statement
Headset
Integrated, Sealed Cartridge
Seat
Saddle
GT MTB
Seatpost
Alloy Micro Adjust, 27.2 x 300mm (XS-M), 350mm (L-XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 142 cm | 151 cm | 164 cm | 176 cm | 184 cm |
| Rider Max Height | 154 cm | 167 cm | 179 cm | 187 cm | 198 cm |
