Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork Suntour MOBIE
-
Groupset XT, Deore -
Suspension Full -
Motor Bosch hub-drive -
Battery Bosch InTube 800Wh -
Drivetrain 1 × 12 -
Brakes Magura Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Uni
Suspension Fork
Suntour MOBIE36-Boost EQ 2CR-PCS DS 15AH2-110 140 mm
Rear Shock
Suntour RS24 Edge X 2CR 205x60mm, Trunnion
Drivetrain
Rear Derailleur
Shimano Deore XT RD-M8100-SGS 12s, Shadow+
Shift Levers
Shimano Triggershift Deore SL-M6100-R, Rapidfire+
Cassette
Shimano Deore CS-M6100-12, MICRO SPLINE
Crank
Miranda Crius ISIS Crankset + Chainring for Bosch BDU38 165
Bottom Bracket
Bosch, press-fit
Chain
Shimano Chain Deore CN-M6100 12s
Pedals
VP VPE-527 Alloy w/ Reflector
Wheels
Rims
Schurmann YAK Disc 25-584 32H 6,5 mm Valve
Tires
Schwalbe Johnny Watts w/ reflective line 60-584
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT C Allroad ABS, 4 pistons, 203 mm
Cockpit
Handlebar
Haibike Flat bar TheBar++ Dia. 31.8 mm
Seat
Saddle
Prologo Proxim W400 Performance 153 mm
Seatpost
Limotec Dropperpost A4H Dropper, Dia. 34.9 mm, Travel: 150 mm
Motor & Battery
Motor
Bosch
Battery
Bosch InTube 800Wh
Charger
Bosch Charger 4A 220-240V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
