Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RockShox 35 Gold RL -
Groupset NX Eagle, SX Eagle -
Suspension Full -
Motor Yamaha mid-drive -
Battery Yamaha Li-ION -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
156cm - 167cm
MD
165cm - 175cm
LG
173cm - 184cm
XL
182cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Aluminium Unisex
Suspension Fork
Rockshox 35 Gold RL
Rear Shock
Rockshox Air Deluxe Select
Drivetrain
Rear Derailleur
SRAM NX NX Eagle
Shift Levers
SRAM Triggershift SX Eagle Single Click
Cassette
SRAM Cassette NX Eagle
Bottom Bracket
integrated in the motor
Chain
SRAM Chain SX Eagle
Pedals
Freeridepedal
Wheels
Rims
WTB Hollow rim ST i30 TCS
Tires
Continental Ruban Reflex 58-622
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT5
Cockpit
Handlebar
Haibike TheBar ++
Seat
Saddle
Selle Royal Vivo
Motor & Battery
Motor
Yamaha
Battery
Yamaha Li-ION
Charger
Yamaha Quick Charger Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.522 mm | 1.519 mm | 1.47 mm | 1.396 mm |
| Front Center | 735 mm | 739 mm | 763 mm | 797 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 106 mm | 100 mm | 100 mm | 100 mm |
| Stack | 624 mm | 638 mm | 647 mm | 656 mm |
| Reach | 410 mm | 420 mm | 440 mm | 470 mm |
| Top Tube Length | 562 mm | 576 mm | 598 mm | 630 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 65 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 130 mm | 140 mm | 150 mm | 160 mm |
| Chainstay Length | 477 mm | 477 mm | 477 mm | 477 mm |
| Wheelbase | 1210 mm | 1214 mm | 1238 mm | 1272 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 165 cm | 173 cm | 182 cm |
| Rider Max Height | 167 cm | 175 cm | 184 cm | 193 cm |
