Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork Fox AWL
-
Groupset GX Eagle -
Suspension Full -
Motor Yamaha mid-drive -
Battery Yamaha InTube 720Wh -
Drivetrain 1 × 12 -
Brakes Magura MT5 Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Aluminium Uni
Suspension Fork
FOX Factory 34 Float AWL Sweep Adjust 140 mm
Rear Shock
FOX Factory Float Performance EVOL LV Trunnion 205x60mm
Drivetrain
Rear Derailleur
SRAM GX Eagle 12s
Shift Levers
SRAM Triggershift GX Eagle Single Click
Cassette
SRAM PG-1230 Eagle, HG
Crank
Samox ISIS Crankarm 165 mm + SRAM Chainring X-SYNC Eagle 165
Chain
SRAM Chain NX Eagle 12s
Pedals
XLC VPE-527 MTB Alloy Pedal w. Reflector
Wheels
Rims
29
Tires
Schwalbe Johnny Watts Performance, Raceguard 67EPI 60-622
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT5, 203 mm
Cockpit
Handlebar
Haibike TheBar++ Dia. 31.8 mm
Seat
Saddle
Prologo Proxim W400 T2.0 153 mm
Seatpost
Limotec Dropperpost A4H Dropper, Dia. 34.9 mm, Travel: 170 mm
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 720Wh
Charger
Yamaha Standard Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
