Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Fork RockShox 35 Silver
-
Groupset Deore -
Suspension Hardtail -
Motor Yamaha mid-drive -
Battery Yamaha InTube 630 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 169cm
MD
167cm - 178cm
LG
176cm - 188cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Aluminium
Suspension Fork
Rockshox 35 Silver 160 mm
Rear Shock
Suntour Air Edge LO-R8 160 mm
Drivetrain
Rear Derailleur
Shimano Deore M5100
Shift Levers
Shimano Triggershift Deore M5100
Cassette
Sunrace CSMS7
Crank
Haibike The Crank +
Bottom Bracket
integrated in the motor
Chain
KMC Chain X11e
Pedals
Freeridepedal
Wheels
Rims
Rodi Hollow rim Tryp 30
Tires
Continental Trail King 60-622
Brakes
Brakes
Front: Tektro Hydraulic Disc brake Orion M745
Cockpit
Handlebar
Haibike TheBar +++ Gravity Dia. 31.8 mm
Seat
Saddle
Selle Royal Vivo
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 630 Wh
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.567 mm | 1.477 mm | 1.41 mm | 1.361 mm |
| Stack | 636 mm | 641 mm | 650 | 663 mm |
| Reach | 406 mm | 434 mm | 461 mm | 487 mm |
| Top Tube Length | 600 mm | 630 mm | 660 mm | 690 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 115 mm | 120 mm | 130 mm | 145 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 167 cm | 176 cm | 186 cm |
| Rider Max Height | 169 cm | 178 cm | 188 cm | 198 cm |
