Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Fork RockShox Psylo
-
Groupset SLX, Deore -
Suspension Full -
Motor Bosch hub-drive -
Battery Bosch InTube 800Wh -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Uni
Suspension Fork
Rockshox Psylo Gold RC 160 mm
Rear Shock
Rockshox Deluxe Select+ RT 205x65mm, DebonAir+
Drivetrain
Rear Derailleur
Shimano SLX RD-M7100 12s, Shadow+
Shift Levers
Shimano Triggershift Deore SL-M6100, Rapidfire+
Cassette
Shimano SLX CS-M7100-12, MICRO SPLINE
Crank
Miranda Crius ISIS Crankarm 160 mm + Chainring 160
Chain
Shimano Chain Deore CN-M6100 12s
Pedals
XLC VPE-527 MTB Alloy Pedal w. Reflector
Wheels
Rims
WTB ST i30 TCS 2.0 32H
Tires
Continental Kryptotal-Fr, Trail Endurance 60-622
Brakes
Brakes
Front: Shimano Hydraulic Disc brake Deore BR-MT420, 4 pistons 203 mm
Cockpit
Handlebar
Haibike TheBar++ Dia. 31.8 mm
Seat
Saddle
Prologo Proxim W400 Performance
Seatpost
Limotec Dropperpost A1H Dropper, Dia. 34.9 mm, Travel: 125 mm
Motor & Battery
Motor
Bosch
Battery
Bosch InTube 800Wh
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
