Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox Yari RC
-
Groupset NX Eagle -
Suspension Full -
Motor Bosch hub-drive -
Battery Bosch InTube 750 Wh -
Drivetrain 1 × 12 -
Brakes Magura MT5 Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Carbon/Aluminium
Suspension Fork
Rockshox Suspension Yari RC 160 mm
Rear Shock
Rockshox Air Deluxe Select Plus 160 mm
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM Triggershift SL Eagle
Cassette
SRAM Eagle PG1210
Crank
Haibike The Crank ++
Bottom Bracket
integrated in the motor
Chain
SRAM Chain SX Eagle
Pedals
Freeridepedal
Wheels
Rims
Rodi Hollow rim Tryp 30
Tires
Maxxis Minion DHF II 65-622
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT5
Cockpit
Handlebar
Haibike TheBar ++ Dia. 31.8 mm
Seat
Saddle
Selle Royal Vivo
Seatpost
Dropperpost
Motor & Battery
Motor
Bosch
Battery
Bosch InTube 750 Wh
Charger
Bosch Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
