Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RockShox Psylo
-
Groupset NX Eagle -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch InTube 800Wh -
Drivetrain 1 × 12 -
Brakes Magura Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Uni
Suspension Fork
Rockshox Psylo Silver RC 120 mm
Drivetrain
Rear Derailleur
SRAM NX Eagle 12s
Shift Levers
SRAM Triggershift NX Eagle Single Click Trigger
Cassette
SRAM PG-1210 Eagle, HG
Crank
Miranda Crius ISIS CRNKS + SRAM CR T-Type Bosch DU38, DM 170
Bottom Bracket
Bosch, press-fit
Chain
SRAM Chain SX Eagle 12s
Pedals
VP VPE-527 Alloy w/ Reflector
Wheels
Rims
WTB ST i30 TCS 2.0 29" 32H
Tires
Schwalbe Nobby Nic Performance, ADDIX, 67EPI 65-622
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT C Allroad ABS, 4 pistons, 203 mm
Cockpit
Handlebar
XLC Riser Bar MTB CAT4, Dia. 31.8 mm, Rise: 15 mm, backsweep 9°
Seat
Saddle
Selle Royal Vivo Ergo 1217HRN
Seatpost
Limotec Dropperpost A1H Dropper, Dia. 34.9 mm, Travel: 125 mm 402 mm
Motor & Battery
Motor
Bosch
Battery
Bosch InTube 800Wh
Charger
Bosch Charger 4A 220-240V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
