Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch PowerTube 500Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
167cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Hardtail Aluminium
Suspension Fork
Suntour XCM32 Boost DS 120 mm
Drivetrain
Rear Derailleur
Shimano Cues U3020 9s
Shift Levers
Shimano Triggershift Cues U4000, Rapidfire
Cassette
Shimano Cues LG300-9, HG
Crank
Miranda Virage 165 mm
Bottom Bracket
integrated in the motor
Chain
Shimano Chain CN-LG500
Pedals
Haibike Freeridepedal
Wheels
Rims
Schürmann Hollow rim Yak25
Tires
WTB Ranger Comp 55-584
Brakes
Brakes
Front: Alhonga Hydraulic Disc brake HT472, 180 mm
Cockpit
Handlebar
XLC 720 mm
Seat
Saddle
XLC MTB
Motor & Battery
Motor
Bosch
Battery
Bosch PowerTube 500Wh
Charger
Bosch Standard Charger 4Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.541 mm | 1.449 mm |
| Bottom Bracket Height | 301 mm | 301 mm |
| Front Center | 732 mm | 768 mm |
| Rake | 54 mm | 53 mm |
| Trail | 106 mm | 107 mm |
| Stack | 624 mm | 633 mm |
| Reach | 405 mm | 437 mm |
| Top Tube Length | 574 mm | 610 mm |
| Seat Tube Angle | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 450 mm |
| Head Tube Angle | 65 ° | 65 ° |
| Head Tube Length | 125 mm | 135 mm |
| Chainstay Length | 490 mm | 490 mm |
| Wheelbase | 1217 mm | 1253 mm |
| Bottom Bracket Drop | 54 mm | 54 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 157 cm | 167 cm |
| Rider Max Height | 169 cm | 180 cm |
