Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch InTube 500Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Uni
Suspension Fork
Suntour XCM32 Boost DS 120 mm
Drivetrain
Rear Derailleur
Shimano Cues RD-U3020 9s
Shift Levers
Shimano Triggershift Cues SL-U4000, Rapidfire+
Cassette
Shimano Cues CS-LG300-9, HG
Crank
Miranda Crankset No. 7, PSI 165 mm + direct mount chainring 165
Chain
Shimano Chain Cues CN-LG500 9s
Pedals
XLC VPE-527 MTB Alloy Pedal w. Reflector
Wheels
Rims
Schurmann Yak25 32H
Tires
WTB Ranger Comp 55-584
Brakes
Brakes
Front: Alhonga Hydraulic Disc brake HT472, 2 postions 180 mm
Cockpit
Handlebar
Kalloy MTB Dia. 31.8 mm, Rise: 15 mm
Seat
Saddle
XLC MTB DDK Active 2373A
Seatpost
Kalloy Non Suspension SP-DC1, Dia. 31.6 mm, L: 300 mm
Motor & Battery
Motor
Bosch
Battery
Bosch InTube 500Wh
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
