Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset microSHIFT Advent X -
Suspension Hardtail -
Motor Yamaha mid-drive -
Battery Yamaha InTube 720 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
168cm - 179cm
LG
177cm - 188cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Unisex
Suspension Fork
Suntour XCM32 Boost DS 120 mm
Drivetrain
Rear Derailleur
MicroSHIFT RD-M6205GM
Shift Levers
MicroSHIFT Triggershift SL-M9505-R
Cassette
MicroSHIFT CS-H104
Crank
Miranda Kies
Bottom Bracket
integrated in the motor
Chain
KMC Chain e10S
Pedals
Freeridepedal
Wheels
Rims
Rodi Hollow rim Tryp 30
Tires
Schwalbe Nobby Nic Performance 65-622
Brakes
Brakes
Front: Shimano Hydraulic Disc brake MT201
Cockpit
Handlebar
XLC RB12L Dia. 31.8 mm
Seat
Saddle
XLC MTB
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 720 Wh
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.511 mm | 1.466 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Front Center | 748 mm | 772 mm | 796 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 104 mm | 104 mm | 104 mm |
| Stack | 674 mm | 683 mm | 692 mm |
| Reach | 432 mm | 452 mm | 472 mm |
| Top Tube Length | 625 mm | 648 mm | 670 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1216 mm | 1240 mm | 1264 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 177 cm | 186 cm |
| Rider Max Height | 179 cm | 188 cm | 198 cm |
