Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset microSHIFT Advent X -
Suspension Hardtail -
Motor Yamaha mid-drive -
Battery Yamaha InTube 720 Wh -
Drivetrain 1 × 10 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Uni
Suspension Fork
Suntour XCM32 Boost DS 120 mm
Drivetrain
Rear Derailleur
MicroSHIFT RD-M6205GM
Shift Levers
MicroSHIFT Triggershift SL-M9505-R
Cassette
MicroSHIFT CS-H104
Crank
Miranda Kies
Bottom Bracket
integrated in the motor
Chain
KMC Chain e10S
Pedals
Freeridepedal
Wheels
Rims
Rodi Hollow rim Tryp 30
Tires
Schwalbe Nobby Nic Performance 65-622
Brakes
Brakes
Front: Shimano Hydraulic Disc brake MT201
Cockpit
Handlebar
XLC RB12L Dia. 31.8 mm
Seat
Saddle
XLC MTB
Seatpost
Non Suspension
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 720 Wh
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
