Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RockShox Psylo -
Groupset SX Eagle -
Suspension Rigid -
Motor Yamaha mid-drive -
Battery Yamaha -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Uni
Suspension Fork
Rockshox Psylo Silver RC 130 mm
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM Triggershift SL Eagle
Cassette
SRAM PG-1210
Crank
Miranda Kies
Bottom Bracket
integrated in the motor
Chain
SRAM Chain CN SX Eagle
Pedals
Freeridepedal
Wheels
Rims
WTB Hollow rim ST i30 TCS
Tires
Schwalbe Nobby Nic Performance 65-622
Brakes
Brakes
Front: Shimano Hydraulic Disc brake MT420
Cockpit
Handlebar
Haibike TheBar ++ Dia. 31.8 mm
Seat
Saddle
Selle Royal Vivo Unitech
Seatpost
Non Suspension
Motor & Battery
Motor
Yamaha
Battery
Yamaha
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
