Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RockShox 35 Silver -
Groupset SX Eagle -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch Li-ION -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
161cm - 171cm
MD
169cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Unisex
Suspension Fork
Rockshox 35 Silver
Drivetrain
Rear Derailleur
SRAM SX Eagle SX Eagle
Shift Levers
SRAM Triggershift SX Eagle
Cassette
SRAM Cassette PG1210
Bottom Bracket
integrated in the motor
Chain
SRAM Chain SX Eagle
Pedals
Freeridepedal
Wheels
Rims
WTB Hollow rim ST i30 TCS
Brakes
Brakes
Front: Shimano Hydraulic Disc brake MT420
Cockpit
Handlebar
Haibike TheBar ++
Seat
Saddle
Selle Royal Vivo Unitech
Motor & Battery
Motor
Bosch
Battery
Bosch Li-ION
Charger
Bosch Standard Charger 4Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.555 mm | 1.519 mm |
| Bottom Bracket Height | 295 mm | 295 mm |
| Front Center | 712 mm | 722 mm |
| Rake | 44 mm | 44 mm |
| Trail | 96 mm | 96 mm |
| Stack | 656 mm | 656 mm |
| Reach | 422 mm | 432 mm |
| Top Tube Length | 610 mm | 620 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 140 mm | 140 mm |
| Chainstay Length | 465 mm | 465 mm |
| Wheelbase | 1171 mm | 1181 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 161 cm | 169 cm |
| Rider Max Height | 171 cm | 180 cm |
