Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour XCT
-
Groupset CUES -
Suspension Hardtail -
Motor Yamaha mid-drive -
Battery Yamaha InTube 400 Wh -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Hardtail Aluminium
Suspension Fork
Suntour XCT-JR-L 63 mm
Drivetrain
Rear Derailleur
Shimano Cues U4000
Shift Levers
Shimano Triggershift Cues
Cassette
Sunrace Cassette CSM90
Crank
Haibike The Crank ++
Bottom Bracket
integrated in the motor
Chain
Shimano Chain Cues LG
Pedals
Wellgo LU984DU
Wheels
Rims
Rodi Hollow rim FW Disc
Tires
Schwalbe Billy Bonkers 50-507
Brakes
Brakes
Front: Tektro Hydraulic Disc brake M282
Cockpit
Handlebar
Haibike TheBar + Topflat Dia. 31.8 mm
Seat
Saddle
Haibike TheSaddle Kids
Seatpost
Haibike Non Suspension
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 400 Wh
Charger
Yamaha Quick charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS |
|---|---|---|
| Wheels | 24" | 24" |
