Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch PowerTube 500Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 168cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Hardtail Aluminium
Suspension Fork
Suntour XCM32 Boost DS 120 mm
Drivetrain
Rear Derailleur
Shimano Cues U3020 9s
Shift Levers
Shimano Triggershift Cues U4000, Rapidfire
Cassette
Shimano Cues LG300-9, HG, HG
Crank
Haibike Aluminium
Bottom Bracket
integrated in the motor
Chain
Shimano Chain CN-LG500
Pedals
Haibike Freeridepedal
Wheels
Rims
Schürmann Hollow rim Yak25
Tires
WTB Ranger Comp 55-584
Brakes
Brakes
Front: Alhonga Hydraulic Disc brake HT472 180 mm
Cockpit
Handlebar
XLC RL12L
Seat
Saddle
XLC MTB
Motor & Battery
Motor
Bosch
Battery
Bosch PowerTube 500Wh
Charger
Bosch Compact charger 2Ah
Fit data
Geometry
