Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch InTube 500Wh -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mid Aluminium Uni
Suspension Fork
Suntour XCM32 Boost DS 120 mm
Drivetrain
Rear Derailleur
Shimano Cues RD-U3020 9s
Shift Levers
Shimano Triggershift Cues SL-U4000, Rapidfire+
Cassette
Shimano Cues CS-LG300-9, HG
Crank
Miranda PSI BNI Crankarm 165 mm + direct mount Chainring 165
Chain
Shimano Chain Cues CN-LG500 9s
Pedals
XLC VPE-527 MTB Alloy Pedal w. Reflector
Wheels
Rims
Schurmann Yak25 Disc 32H with single eyelets
Tires
WTB Ranger Comp 55-584
Brakes
Brakes
Front: Alhonga Hydraulic Disc brake HT472, 2 postions 180 mm
Cockpit
Handlebar
Kalloy MTB Dia. 31.8 mm, Rise: 15 mm
Seat
Saddle
XLC MTB DDK Active 2373A
Seatpost
Kalloy Non Suspension SP-DC1 Dia. 31.6 mm, L: 300 mm
Motor & Battery
Motor
Bosch
Battery
Bosch InTube 500Wh
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM |
|---|---|---|
| Wheels | 27" | 27" |
