Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GX Eagle -
Suspension Rigid -
Motor Bosch hub-drive -
Battery Bosch PowerTube 750 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
168cm - 176cm
LG
174cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Aluminium
Drivetrain
Rear Derailleur
SRAM RD GX Eagle
Shift Levers
SRAM Triggershift SL Eagle
Cassette
SRAM PG-1210
Crank
Haibike The Crank ++
Bottom Bracket
integrated in the motor
Chain
SRAM Chain CN SX Eagle
Pedals
Freeridepedal
Wheels
Rims
Rodi Hollow rim Tryp 30
Brakes
Brakes
Front: Shimano Hydraulic Disc brake MT420
Cockpit
Handlebar
Haibike TheBar ++ Dia. 31.8 mm
Seat
Saddle
Selle Royal Vivo
Motor & Battery
Motor
Bosch
Battery
Bosch PowerTube 750 Wh
Charger
Bosch Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.498 mm | 1.455 mm | 1.418 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Front Center | 751 mm | 768 mm | 785 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 119 mm | 119 mm | 119 mm |
| Stack | 629 mm | 633 mm | 638 mm |
| Reach | 420 mm | 435 mm | 450 mm |
| Top Tube Length | 573 mm | 589 mm | 605 mm |
| Seat Tube Angle | 76.3 ° | 76.3 ° | 76.3 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 140 mm | 145 mm | 145 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1205 mm | 1222 mm | 1239 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 160 cm | 168 cm | 174 cm |
| Rider Max Height | 170 cm | 176 cm | 184 cm |
