Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork Fox AWL
-
Groupset NX Eagle, SX Eagle -
Suspension Full -
Motor Bosch hub-drive -
Battery Bosch InTube 800Wh -
Drivetrain 1 × 12 -
Brakes Magura Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
LOW Aluminium Uni
Suspension Fork
FOX Factory 34 Float AWL Sweep Adjust 140 mm
Rear Shock
FOX Factory Float Factory 185x55mm, Trunnion, 2 Pos. Lev.
Drivetrain
Rear Derailleur
SRAM NX Eagle 12s
Shift Levers
SRAM Triggershift SX Eagle Single Click
Cassette
SRAM PG-1210 Eagle, HG
Crank
Samox ISIS Alloy Crankarm 165 mm + SRAM Chainring T-Type 165
Chain
SRAM Chain SX Eagle 12s
Pedals
XLC VPE-527 MTB Alloy Pedal w. Reflector
Wheels
Rims
WTB ST i30 TCS 2.0 32H
Tires
Continental Xynotal Trail Endurance 60-584
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT C Allroad ABS 4 pistons, 203 mm
Cockpit
Handlebar
Haibike TheBar++ Dia. 31.8 mm
Seat
Saddle
Selle Royal Vivo 1216HRN
Seatpost
Limotec Dropperpost A1H Dropper, Dia. 34.9 mm, Travel: 125 mm
Motor & Battery
Motor
Bosch
Battery
Bosch InTube 800Wh
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
