Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork RockShox Psylo
-
Groupset SX Eagle -
Suspension Full -
Motor Yamaha mid-drive -
Battery Yamaha InTube 720Wh -
Drivetrain 1 × 12 -
Brakes TRP Slate EVO Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Aluminium Uni
Suspension Fork
Rockshox Psylo Gold RC 140 mm
Rear Shock
Rockshox Deluxe Select 205x57,5mm, Trunnion, DebonAir+
Drivetrain
Rear Derailleur
SRAM SX Eagle 12s
Shift Levers
SRAM Triggershift SX Eagle Single Click
Cassette
SRAM PG-1210 Eagle, HG
Chain
SRAM Chain SX Eagle 12s
Pedals
XLC VPE-527 MTB Alloy Pedal w. Reflector
Wheels
Rims
WTB ST i30 TCS 2.0 32H
Tires
Schwalbe Nobby Nic Evo, Super Ground, TLE 62-622
Brakes
Brakes
Front: TRP Hydraulic Disc brake Slate EVO HD-M807, 203 mm
Cockpit
Handlebar
Haibike TheBar++ Dia. 31.8 mm
Seat
Saddle
Selle Royal Vivo 1216HRN
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 720Wh
Charger
Yamaha Standard Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
