Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset SLX, Deore -
Suspension Rigid -
Motor Bosch hub-drive -
Battery Bosch PowerTube 625 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
168cm - 179cm
LG
177cm - 187cm
XL
185cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Aluminium
Drivetrain
Rear Derailleur
Shimano SLX M7100
Shift Levers
Shimano Triggershift Deore M6100
Cassette
Shimano M6100
Crank
Haibike The Crank ++
Bottom Bracket
integrated in the motor
Chain
Shimano Chain CN-M6100
Pedals
Freeridepedal
Wheels
Rims
Rodi Hollow rim Tryp 30
Brakes
Brakes
Front: Shimano Hydraulic Disc brake MT420
Cockpit
Handlebar
Haibike TheBar ++ Dia. 31.8 mm
Seat
Saddle
Selle Royal Vivo
Motor & Battery
Motor
Bosch
Battery
Bosch PowerTube 625 Wh
Charger
Bosch Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.422 mm | 1.357 mm | 1.297 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 774 mm | 800 mm | 827 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 128 mm | 129 mm | 128 mm |
| Stack | 633 mm | 638 mm | 642 mm |
| Reach | 445 mm | 470 mm | 495 mm |
| Top Tube Length | 599 mm | 625 mm | 652 mm |
| Seat Tube Angle | 76.3 ° | 76.3 ° | 76.3 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 130 mm | 135 mm | 140 mm |
| Chainstay Length | 477 mm | 477 mm | 477 mm |
| Wheelbase | 1249 mm | 1275 mm | 1303 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 177 cm | 185 cm |
| Rider Max Height | 179 cm | 187 cm | 196 cm |
