Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RockShox 35 Gold RL -
Groupset NX Eagle -
Suspension Full -
Motor Yamaha mid-drive -
Battery Yamaha InTube 750 Wh -
Drivetrain 1 × 12
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 178cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Aluminium
Suspension Fork
RockShox 35 Gold RL, Travel: 140mm
Rear Shock
Rockshox Air Deluxe Select Plus 140 mm
Drivetrain
Rear Derailleur
SRAM, NX Eagle
Shift Levers
SRAM Triggershift NX Eagle
Cassette
SRAM Eagle PG1210
Crank
Haibike The Crank ++
Bottom Bracket
integrated in the motor
Chain
SRAM Chain SX Eagle
Chain Guide
Nylon directmount
Pedals
Freeridepedal
Wheels
Rims
WTB, ST i30 TCS, Double Wall
Spokes
Sapim, Race, Black
Tires
Schwalbe, Magic Mary Evo TLE, 65-622, 29" x 2.6"
Brakes
Brakes
No
Brake Levers
Magura, MT5 HC-lever,
Cockpit
Stem
Alu, A-head, 31.8 mm
Handlebar
Haibike TheBar +++ Dia. 31.8 mm
Headset
Acros, BlockLock, Aluminium
Seat
Saddle
Selle Royal Vivo
Seatpost
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 750 Wh
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.435 mm | 1.347 mm | 1.284 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Front Center | 764 mm | 778 mm | 800 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 117 mm | 116 mm | 116 mm |
| Stack | 623 mm | 610 mm | 610 mm |
| Reach | 434 mm | 453 mm | 475 mm |
| Top Tube Length | 577 mm | 593 mm | 615 mm |
| Seat Tube Angle | 77.1 ° | 77.1 ° | 77.1 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 145 mm | 130 mm | 130 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1223 mm | 1237 mm | 1259 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 160 cm | 169 cm | 176 cm |
| Rider Max Height | 171 cm | 178 cm | 187 cm |
