Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RockShox 35 Silver
-
Groupset SLX, Deore -
Suspension Hardtail -
Motor Yamaha mid-drive -
Battery Yamaha InTube 630 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
168cm - 178cm
LG
176cm - 186cm
XL
184cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Hardtail Aluminium
Suspension Fork
Rockshox 35 Silver 120 mm
Drivetrain
Rear Derailleur
Shimano SLX M7100
Shift Levers
Shimano Triggershift Deore M6100
Cassette
Shimano M6100
Crank
Haibike geschmiedet
Bottom Bracket
integrated in the motor
Chain
Shimano Chain CN-M6100
Pedals
Freeridepedal
Wheels
Rims
Rodi Hollow rim Tryp 30
Tires
WTB Ranger Comp 65-622
Brakes
Brakes
Front: Shimano Hydraulic Disc brake MT410
Cockpit
Handlebar
XLC Topflat Dia. 31.8 mm
Seat
Saddle
XLC MTB
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 630 Wh
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.469 mm | 1.403 mm | 1.373 mm |
| Stack | 648 mm | 661 mm | 684 mm |
| Reach | 441 mm | 471 mm | 498 mm |
| Top Tube Length | 608 mm | 619 mm | 675 mm |
| Seat Tube Angle | 76 ° | 77.4 ° | 76 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 115 mm | 135 mm | 160 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 176 cm | 184 cm |
| Rider Max Height | 178 cm | 186 cm | 196 cm |
