Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Fork Fox Factory Float 38 -
Groupset GX Eagle Transmission, GX Eagle AXS -
Suspension Full -
Motor Bosch hub-drive -
Battery Bosch Li-ION PowerTube 750 Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
167cm - 178cm
LG
176cm - 187cm
XL
185cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Carbon/Aluminium Unisex
Suspension Fork
FOX Factory 38 Factory Grip 2
Rear Shock
FOX Factory Air Float X Factory 205X65
Drivetrain
Rear Derailleur
SRAM GX Eagle T-Type AXS 12SPD
Shift Levers
SRAM GX Eagle AXS
Cassette
SRAM XG 175 EAGLE 10-50
Crank
Samox HB25 IS165 165
Bottom Bracket
integrated in the motor
Chain
SRAM Chain SX Eagle 12S
Pedals
VP VP-527
Wheels
Rims
29
Tires
Maxxis Minion DHF II 65-622
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT5
Cockpit
Handlebar
Race Face Riser Bar ATLAS 0.5 RISER
Seat
Saddle
Selle Italia X BLACK
Motor & Battery
Motor
Bosch
Battery
Bosch Li-ION PowerTube 750 Wh
Charger
Bosch quick charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.534 mm | 1.46 mm | 1.376 mm | 1.306 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 737 mm | 769 mm | 806 mm | 842 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 130 mm | 130 mm | 130 mm | 130 mm |
| Stack | 626 mm | 635 mm | 644 mm | 653 mm |
| Reach | 408 mm | 435 mm | 468 mm | 500 mm |
| Top Tube Length | 560 mm | 590 mm | 625 mm | 660 mm |
| Seat Tube Angle | 76.3 ° | 76.3 ° | 76.3 ° | 76.3 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1191 mm | 1223 mm | 1260 mm | 1296 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 790 mm | 810 mm | 830 mm | 830 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 157 cm | 167 cm | 176 cm | 185 cm |
| Rider Max Height | 169 cm | 178 cm | 187 cm | 196 cm |
