Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Fork RockShox ZEB Select -
Groupset NX Eagle -
Suspension Full -
Motor Bosch hub-drive -
Battery Bosch Li-ION PowerTube -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
167cm - 178cm
LG
176cm - 187cm
XL
185cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Carbon/Aluminium Unisex
Suspension Fork
Rockshox ZEB Select RC
Rear Shock
Rockshox Air Deluxe Select Plus
Drivetrain
Rear Derailleur
SRAM NX EAGLE 12S
Cassette
SRAM 12S PG-1210 11-50
Crank
Samox HB25 IS 165 165
Bottom Bracket
integrated in the motor
Chain
SRAM Chain CN SX EAGLE 126
Pedals
VP Freeridepedal
Wheels
Rims
WTB Hollow rim ST i30 TCS
Tires
Maxxis Minion DHF II 65-622
Brakes
Brakes
Front: Shimano Hydraulic Disc brake SLX M7120
Cockpit
Handlebar
JD MTB563A.2 780
Seat
Saddle
Selle Italia X BLACK
Motor & Battery
Motor
Bosch
Battery
Bosch Li-ION PowerTube
Charger
Bosch quick charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.534 mm | 1.46 mm | 1.376 mm | 1.306 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 737 mm | 769 mm | 806 mm | 842 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 130 mm | 130 mm | 130 mm | 130 mm |
| Stack | 626 mm | 635 mm | 644 mm | 653 mm |
| Reach | 408 mm | 435 mm | 468 mm | 500 mm |
| Top Tube Length | 560 mm | 590 mm | 625 mm | 660 mm |
| Seat Tube Angle | 76.3 ° | 76.3 ° | 76.3 ° | 76.3 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1191 mm | 1223 mm | 1260 mm | 1296 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 790 mm | 810 mm | 830 mm | 830 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 157 cm | 167 cm | 176 cm | 185 cm |
| Rider Max Height | 169 cm | 178 cm | 187 cm | 196 cm |
