Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Rear 140mm -
Fork Fox Factory Float 36 -
Groupset XX Eagle Transmission, X01 Eagle AXS -
Suspension Full -
Motor Fazua hub-drive -
Battery Fazua PowerTube 430 Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
159cm - 170cm
MD
168cm - 179cm
LG
177cm - 187cm
XL
185cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Carbon
Suspension Fork
FOX Factory 36 Float Factory 140 mm
Rear Shock
FOX Factory Air Float X Factory 140 mm
Drivetrain
Rear Derailleur
SRAM XX Eagle T-Type
Shift Levers
SRAM Triggershift AXS Pod Controller
Cassette
SRAM XX T-Type
Crank
Rotor E-Kapic
Bottom Bracket
integrated in the motor
Chain
SRAM Chain X0 T-Type
Pedals
XLC Freeridepedal
Wheels
Rims
29
Tires
Maxxis Dissector MaxxTerra EXO 62-622
Brakes
Brakes
Front: Shimano Hydraulic Disc brake XTR M9120
Cockpit
Handlebar
Race Face Next Carbon Dia. 35.0 mm
Seat
Saddle
Fizik Terra Aidon X1-145 Carbon
Motor & Battery
Motor
Fazua
Battery
Fazua PowerTube 430 Wh
Charger
Fazua 3A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.441 mm | 1.372 mm | 1.313 mm | 1.261 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 746 mm | 778 mm | 810 mm | 841 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 126 mm | 126 mm | 126 mm | 126 mm |
| Stack | 611 mm | 620 mm | 629 mm | 638 mm |
| Reach | 424 mm | 452 mm | 479 mm | 506 mm |
| Top Tube Length | 562 mm | 592 mm | 622 mm | 652 mm |
| Seat Tube Angle | 77.3 ° | 77.3 ° | 77.3 ° | 77.3 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1195 mm | 1227 mm | 1259 mm | 1290 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 159 cm | 168 cm | 177 cm | 185 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm | 196 cm |
