Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 180mm -
Travel Rear 180mm -
Fork Öhlins DH38 M.1
-
Groupset GX Eagle -
Suspension Full -
Motor Yamaha mid-drive -
Battery Yamaha InTube 720 Wh -
Drivetrain 1 × 12 -
Brakes Magura MT7 Pro Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Fully Aluminium
Suspension Fork
Ohlins Öhlins DH38 M.1 180 mm
Rear Shock
Ohlins Air Öhlins TTX 22 M 180 mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM Triggershift CX Eagle
Cassette
SRAM GX 1275 Eagle
Crank
Haibike The Crank ++
Bottom Bracket
integrated in the motor
Chain
SRAM Chain GX Eagle
Pedals
Freeridepedal
Wheels
Rims
29
Tires
Schwalbe Magic Mary Evo TLE 65-622
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT7
Cockpit
Handlebar
Race Face Atlas Dia. 31.8 mm
Seat
Saddle
Fizik Terra Aidon X5-160
Seatpost
Haibike Dropperpost
Motor & Battery
Motor
Yamaha
Battery
Yamaha InTube 720 Wh
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
