Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 67mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Suntour SF18-XCM-ATB HLO 67 mm
Drivetrain
Rear Derailleur
Shimano Cues RD-U3020 9s, Shadow
Shift Levers
Shimano Triggershift Cues SL-U4000, Rapidfire+
Cassette
Shimano Cues CS-LG300-9, HG
Crank
Miranda PSI BNI Crankarm 170 mm + direct mount Chainring
Chain
Shimano Chain Cues CN-LG500 9s
Pedals
XLC VPE-461 MTB Alloy Pedal w. Reflector
Wheels
Rims
Schurmann Yak25 32H with Single Eyelets
Tires
WTB Groov-E, w/ reflective stripe, 60TPI 62-584
Brakes
Brakes
Front: Alhonga Hydraulic Disc brake HT474, 2 pistons 180 mm
Cockpit
Handlebar
Kalloy HBRB12L Dia. 31.8 mm, Rise: 15 mm
Seat
Saddle
Selle Royal Wave
Seatpost
Kalloy Non Suspension SP-DC1, Dia. 31.6 mm, L: 400 mm
Motor & Battery
Motor
Bosch
Battery
Bosch
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
