Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Altus -
Suspension Hardtail -
Motor Yamaha mid-drive -
Battery Yamaha -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
159cm - 168cm
MD
166cm - 176cm
LG
174cm - 184cm
XL
182cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Suntour NEX E25 63mm
Drivetrain
Rear Derailleur
Shimano Altus M2000
Shift Levers
Shimano Triggershift Alivio M3100
Cassette
Shimano HG200
Crank
Haibike geschmiedet
Bottom Bracket
integrated in the motor
Chain
KMC Chain e9S
Chain Guide
Nylon directmount
Pedals
VP E461
Wheels
Rims
Schürmann Hollow rim Yak25
Spokes
Sapim, Leader, Black
Tires
Continental Contact Urban 55-584
Brakes
Brakes
Front: Tektro Hydraulic Disc brake HD-T275
Brake Levers
Shimano, MT201, Aluminium,
Cockpit
Stem
XLC, A-Head verstellbar, A-head, 31.8 mm
Handlebar
XLC Topflat Dia. 31.8 mm
Headset
Feimin, A-Head Tapered, Aluminium, Cartridge
Seat
Saddle
Selle Royal Wave
Seatpost
Aluminium, Patent, 34.9 mm
Motor & Battery
Motor
Yamaha
Battery
Yamaha
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.595 mm | 1.59 mm | 1.586 mm | 1.572 mm |
| Front Center | 712 mm | 722 mm | 739 mm | 764 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 86 mm | 86 mm | 86 mm | 86 mm |
| Stack | 622 mm | 636 mm | 655 mm | 673 mm |
| Reach | 390 mm | 400 mm | 413 mm | 428 mm |
| Top Tube Length | 580 mm | 595 mm | 613 mm | 633 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 560 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 155 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1171 mm | 1181 mm | 1198 mm | 1223 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 159 cm | 166 cm | 174 cm | 182 cm |
| Rider Max Height | 168 cm | 176 cm | 184 cm | 193 cm |
