Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset XT, Deore -
Suspension Hardtail -
Motor Yamaha mid-drive -
Battery Yamaha -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Rockshox Recon Silver RL 100 mm
Drivetrain
Rear Derailleur
Shimano Deore XT RD-M8100 12s, Shadow+
Shift Levers
Shimano Triggershift Deore SL-M6100, Rapidfire+
Cassette
Shimano Deore CS-M6100-12, MICRO SPLINE
Crank
Miranda Kies ISIS Crankarm 170 mm + Chainring
Chain
Shimano Chain Deore CN-M6100 12s
Pedals
XLC VPE-461 MTB Alloy Pedal w. Reflector
Wheels
Rims
Schurmann Yak25 32H with Single Eyelets
Tires
Schwalbe Johnny Watts with reflective line 60-584
Brakes
Brakes
Front: Shimano Hydraulic Disc brake Deore BR-MT420, 203 mm
Cockpit
Handlebar
JD MTB502A Dia. 31.8 mm, Rise: 25 mm
Seat
Saddle
Selle Royal Essenza+
Seatpost
Limotec Non Suspension A1H Dropper, Dia. 34.9 mm, Travel: 150 mm
Motor & Battery
Motor
Yamaha
Battery
Yamaha
Charger
Yamaha Standard Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm | cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm | cm |
