Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Suntour MOBIE
-
Groupset Nexus -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Magura Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Suntour SF24-MOBIE34-Boost-ABS-EQ-2CR-DS 100 mm
Drivetrain
Shift Levers
Shimano Gripshift Nexus SL-C7000-5, Revoshift Lever
Cassette
Gates CDX rear Sprocket for Shimano Nexus 5 Mech. Hub
Crank
Miranda Crius CRNKS + GATES Sprocket+Spider, 5B, BCD130
Chain
Gates Belt Carbon Drive Belt CDX, 125T
Pedals
VP VPE-527 Alloy w/ Reflector
Wheels
Rims
Schurmann YAK Disc 25-584 32H w/ single eyelets
Tires
Schwalbe Johnny Watts w/ reflective line 60-584
Brakes
Brakes
Front: Magura Hydraulic Disc brake MT C Allroad ABS, 4 pistons, 203 mm
Cockpit
Handlebar
XLC Riser Bar CAT2, Dia. 31.8 mm, Rise: 25 mm, backsweep 15°
Seat
Saddle
Selle Royal Essenza+
Seatpost
Limotec Dropperpost A1H Dropper, Dia. 34.9 mm, Travel: 125 mm
Motor & Battery
Motor
Bosch
Battery
Bosch
Charger
Bosch Charger 4A 220-240V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
