Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haro CK V3 20.75" aftermarket frame. 100% chromoly, 127mm head tube, investment-cast dropouts with inside knurling, built in chain tensioners, gusseted top tube and down tube. Removable brake mounts.
Suspension Fork
Haro CK V3 fork. 100% heat-treated chromoly. Tapered legs, investment cast 5mm dropouts, 24mm offset.
Drivetrain
Cassette
Premium Team sprocket. CNC-alloy, 25T.
Crank
Premium Trestle 3-piece chromoly cranks. 24mm spindle, 165mm length.
Bottom Bracket
Premium sealed mid, 24mm.
Chain
Premium Half Link.
Pedals
Premium Kinetic PC, chromoly spindles.
Wheels
Front Hub
Premium Team sealed bearing, female 3/8" axle, 2X nylon hub guards.
Rear Hub
Premium Team sealed freecoaster, 14mm male axle, 9t chromoly driver, 2X nylon hub guards.
Rims
Premium Varanyak alloy rims. Brakeless design, 40mm width.
Tires
Premium CK. 20 X 2.4" tires.
Brakes
Brakes
Rim
Cockpit
Stem
Premium CK. CNC-alloy. 48mm reach, 25.4mm bore.
Handlebar
Premium CK, 100% butted chromoly. 9" rise. 25.4mm clamping area.
Grips
Premium CK, flangeless.
Headset
Haro integrated headset, sealed bearings.
Seat
Saddle
Premium Denim Pivotal, padded, mid-sized.
Seatpost
Premium Pivotal, alloy.
Fit data
Geometry
