Haro Daley Alloy 2 2025
2025 Mountain
Estimate price |
2,999$
Weight | 17.29 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Travel Rear 140mm -
Fork Marzocchi Bomber Z2
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Tektro Gemini Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haro Daley alloy full-suspension frame, 1-1/8" - 1-1/5" tapered head tube, 148mm Boost OLD, UDH derailleur hanger
Suspension Fork
Marzocchi Bomber Z2, Rail - Sweep Adjust, Kabolt 110 x 15mm thru-axle, 44mm offset, 150mm travel
Rear Shock
Marzocchi Inline R, 140mm travel
Drivetrain
Rear Derailleur
Shimano Deore 12-speed, RD-M6100 Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano Deore Rapid Fire, SL-M6100-R
Cassette
Shimano 12-speed CS-M6100-12, Hyper Glide Plus, 10-51T
Crank
Shimano Deore FC-M6120-1, 165mm 30T, CL:55
Bottom Bracket
Shimano BB-MT501 BSA 68/73mm
Chain
KMC X12
Pedals
N/A
Wheels
Front Hub
Alloy CNC 4 sealed bearings, 110x15 front axle, 148x12 rear axle
Rear Hub
Alloy CNC 4 sealed bearings, 110x15 front axle, 148x12 rear axle
Rims
WTB ST 30, TCS 2.0 pinned double-wall alloy, 28H
Tires
Front: Vittoria Mazza 2.4", enduro G2.0 120TPI / Rear: Vittoria Martello 2.4" enduro G2.0 120TPI
Brakes
Brakes
Tektro Gemini SL 4-piston hydraulic disc, with 2.3mm rotors, 203mm front rotor, 180mm rear rotor
Brake Levers
Tektro Gemini
Cockpit
Stem
Satori Ursa, 31.8 ID, 35mm reach, 0° rise
Handlebar
Alloy 6061-T6 Riser bar, 800mm wide, 20mm rise, 6° back sweep, 4° upsweep
Headset
FSA Orbit 1.5E ZS/ NO.57E tapered headset, 44/56mm head tube
Seat
Saddle
WTB Volt Medium, w/steel rails
Seatpost
Kind Shock I900 34.9 OD. Sizes: Small 150mm, Medium 170mm, Large 200mm, X-Large 200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.347 mm | 1.326 mm | 1.276 mm | 1.231 mm |
| Bottom Bracket Height | 332 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 745 mm | 794 mm | 823 mm | 853 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 120 mm | 121 mm | 121 mm | 120 mm |
| Stack | 579 mm | 610 mm | 619 mm | 628 mm |
| Reach | 430 mm | 460 mm | 485 mm | 510 mm |
| Top Tube Length | 553 mm | 590 mm | 617 mm | 644 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 361 mm | 410 mm | 448 mm | 473 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 428 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1172 mm | 1237 mm | 1266 mm | 1296 mm |
| Bottom Bracket Drop | 23 mm | 33 mm | 33 mm | 33 mm |
| Standover Height | 691 mm | 685 mm | 705 mm | 705 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
