Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RockShox Judy Silver TK
-
Groupset XT, CUES -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed, heat-treated 6061-T6 aluminum hardtail frame. Tapered head tube with double-butted top and down tubes. 148mm Boost rear axle spacing. Internal cable routing. UDH derailleur hanger.
Suspension Fork
Rock Shox Judy Silver TK with crown adjust, 29", 15x110mm axle, Solo Air, 120mm travel
Drivetrain
Rear Derailleur
Shimano XT Linkglide 11-speed
Shift Levers
Shimano Cues 11-speed with optical window
Cassette
Shimano Cues CS-LG400-11, 11-50T
Crank
Shimano Cues 2-piece, FC-U6000-1, 170mm, 32T chainring
Bottom Bracket
Shimano Cues BB-MT501 BSA 73mm
Chain
Shimano Linkglide CN-LG500
Pedals
FPD PC
Wheels
Front Hub
Shimano HB-TC500 Center Lock 32h, 15mm thru-axle
Rear Hub
Shimano FH-TC500, Center lock, 32h, 12mm thru-axle
Rims
Alloy double-wall, pinned seams, 32h w/eyelets
Tires
WTB Trail Boss 29 x 2.4" front and rear
Brakes
Brakes
Shimano MT200 Hydraulic 2-piston disc brake with 180mm rotor front and 160mm rotor rear
Cockpit
Stem
Alloy 6061 Forged 40mm reach
Handlebar
Haro Alloy 6061 Pivot MTB riser bar, 780 wide, 20mm rise
Headset
FSA Orbit sealed, tapered 1-1/8" - 1-1/5" FSA (44/56mm)
Seat
Saddle
WTB Volt Medium
Seatpost
KS I900 dropper post
